KuWFi-AP610H is an 11ac dual-band outdoor wireless access point, 750Mbps data rate, in line with IEEE 802.11ac/b/g/n standard, Qualcomm chipset, 2.4G 300Mbps and 5G 450Mbps high rate, 500mW high power design, N Type antenna connector, suitable for wider outdoor wifi range and more users
The outdoor PoE access point supports wireless AP, WiFi repeater, Bridge, WISP, WDS operation modes, and then has an N-type connector for a detachable full/panel antenna. The user can flexibly choose the appropriate wireless mode to establish or extend Wireless network structure based on existing network
The outdoor WiFi range extender adopts a metal waterproof, dust-proof and sun-proof housing with self-adaptive temperature and can work in harsh outdoor environments. At the same time, the auxiliary heat dissipation function makes HW-AP610 work normally at -20°C to 55°C
If necessary, it supports full frequency and more than 200 channels to avoid Wi-Fi interference and ensure a stable wireless connection. At the same time, it supports Power over Ethernet, IEEE 802.3af PoE, 48V, and it can be easily set even if there is no power outlet nearby.
The last and most important point is that KuWFi-AP610H is centrally managed together with Yunxin's AC controller in the wireless AP operating mode, and then can be used with the cloud server to use the AC controller or KuWFi-AP610H for mandatory portal authentication or advertising;
-------------------------------------------------- -------------------------------------------------- -------------------------------------------------- -------------
Product Description
Delivery instructions
KuWFi outdoor AP supports fast delivery. Fast delivery from China via DHL/UPS international express, and the shipping time only takes 3-5 days. No tax, do you want to get the outdoor wifi extender you want as soon as possible? This will be your best choice
hardware
Chipset: Qualcomm QCA9531 + QCA9887
Wireless: 802.11ac standard, 600Mbps 1T1R
Memory: 128MB DDR2 RAM
Flash memory: 16MB
interface:
-1 10/100 Mbps RJ45 interface, supporting active 48V power supply
-1 * Reset button
Antenna: N connector, can be connected to panel antenna/omnidirectional antenna
LED lights: WAN, LAN
Size: 230mm * 150 mm * 80 mm
Power supply: POE 48V (24V PoE optional); 110V/220V
Max Users: 128
Firmware
Operation mode: AP/WiFi repeater/WISP
Agreement/standard:
-IEEE 802.3 (Ethernet)
-IEEE 802.3u (Fast Ethernet)
-IEEE 802.11ac/b/g/n
Wireless:
-Automatic channel selection
-Distance control (802.1x) Ack timeout)
-Multiple SSID (8 SSID)
-BSSID
Antenna: 8dbi
System settings: Web-based configuration (HTTP/Telnet)
Firmware upgrade: upgrade firmware via web browser or TFTP
Management: Administrator password can be configured
System monitoring: status at hand, useful statistics and event logs
Log: Support local log, log host, log file export
Reset: reset or factory default
Backup: restore device settings and configurations to local files
RF date
Frequency:
2.4G: 802.11b/g/n, 5.8GHz: 802.11a/n/ac MIMO
-2.4GHz: Standard: 2.4GHz~2.484GHz; Special: 2.312GHz to 2.4835GHz
-5GHz: Standard: 5150~5825MHz, special: 5020-6100MHz
Modulation:
-OFDM = BPSK, QPSK, 16-QAM, 64-QAM
-DSSS = DBPSK, DQPSK, CCK4G2
Data rate: 300Mbps & 5.8G: 450Mbps
Package
1 * KuWFi-AP610H unit
1 * User Manual
1 * LAN Cable
